ROOF-CM • Roof explosion proof fans
Description:
ATEX roof exhaust unit with horizontal discharge
Application
ROOF-CMATEX line has been designed for installations where it is necessary to guarantee the correct air extraction avoiding risks of explosion due to flammable gas. For instance, battery rooms, chemical premises, laboratories etc.. For direct or ducted installation on the roof
Composition
- High efficiency backward curved blade impeller in galvanized steel sheet
- Balancing according to UNI – ISO 1940
- Fixing base, with inlet cone, in steel sheet protected against the atmospheric agents
- Protection guard in steel rod protected against the atmospheric agents
- Cap in techno-polymer
- Asynchronous three-phase or mono-phase electric motor, outside the airflow, protection IP 55, insulation class F, S1 service,
construction according to IEC / EEC / UNEL MEC. Flame proof EEx-d. ATEX approved for explosive atmoshpere G GROUP II
- Arrangement 5; directly coupled to the motor shaft
Accessories
- Inlet gravity shutter GS-RH
- Inlet protection grid RA (necessary for use in free air)
- Inlet silencer SIL-RO
